ALC700 Series Light Tower Set Controller
ALC700 Series Light Tower Set Controller 2018-03-02 Version 1.4 Page 13 of 51
5.3 SCHEDULED START/STOP
A. Press ，its indicator light on, and controller enters Auto mode. Meanwhile, the panel
display Auto Mode Select (Fig 1); Press and to select 01 Auto Timer Mode and
press or to confirm (Fig 2); Press and to select 01 Timer Start and
press or to confirm (Fig 3).
B. When there are 10s left from start time, audible alarm relay is active (if configured). When
start time is up and start remaining time is more than 0s, light tower set begin cranking and
flashlight is twinkling (if configured). Stop delay time will be displayed on the first line (Fig
4).
C. If generator voltage and frequency has reached on-load requirements (Voltage≥on-load
voltage and frequency≥on-load frequency), all the lights will illuminate in proper order and
the illumination interval delay is 2s (can be set as 1~300s). (Fig 5,6)
