Smartgen ALC700 SERIES User Manual

ALC700 Series Light Tower Set Controller
ALC700 Series Light Tower Set Controller 2018-03-02 Version 1.4 Page 35 of 51
Parameters
Default
Output Port 2
Common alarm; Normally open output
Output Port 3
Flashlight output; Normally open output
Output Port 4
Audible alarm output; Normally open output
Input Port 1 Custom Delay
2s
Input Port 2 Custom Delay
2s
Input Port 3 Custom Delay
2s
Input Port 4 Custom Delay
2s
Generator Under Frequency
Warn
42.0Hz
Generator Under Frequency
Shut
40.0Hz
Generator Onload
Frequency
45.0Hz
Generator Over Frequency
Warn
55.0Hz
Generator Over Frequency
Return
52.0Hz
Generator Over Frequency
Shut
57.0Hz
Generator Under Voltage
Warn
196V
Generator Under Voltage
Shut
185V
Generator Onload Voltage
207V
Generator Over Voltage
Warn
264V
Generator Over Voltage
Return
253V
Generator Over Voltage
Shut
273V
Over Current Percentage
100%
Delay Ratio
36
Over Current Action
Trip and stop
Crank Disconnect Generator
Frequency
15Hz
Crank Disconnect Engine
Speed
450RPM
Crank Disconnect Oil
Pressure
Not Used
Oil Pressure Detection
During Cranking
No
Battery Low Volt Work Mode
Invalid
Battery Low Volt Set Value
80%
Battery Low Volt Run Time
40min
Light Inputs Settings
Feedback input
