Smartgen HAT700 User Manual

HAT700 SERIES ATS CONTROLLER USER MANUAL
HAT700 Series ATS Controller 2018-12-13 Version 1.5 Page 16 of 51
7.2.8. OTHERS
No.
Item
Description
1
Start Inhibit
Genset start Inhibit is active.
2
S1 Load Inhibit
S1 Load Inhibit input is active.
3
S2 Load Inhibit
S2 Load Inhibit input is active.
4
NEL1 Trip
NEL1 off load signal is output.
5
NEL2 Trip
NEL2 off load signal is output.
6
NEL3 Trip
NEL3 off load signal is output.
7
Remote Gen On Load
Remote start (on load) signal is active.
8
Remote Gen Off Load
Remote start (off load) signal is active.
9
Gen Start Mains NG
Start genset when mains is abnormal.
10
Cycle Gen Start Mode
Cycle Run Start Mode is active when “S1 Gens S2 Gens” system
is active.
11
Balance Gen Hours Mode
Balance Run Start Mode is active when “S1 Gens S2 Gens”
system is active.
12
Master-Slave Gen Start
Mode
Master Run Start Mode is active when “S1 Gens S2 Gens”
system is active.
13
Auto Mode
Current mode is Auto mode.
14
Manual Mode
Current mode is Manual mode.
7.3 MAIN MENU
In the main screen, press key will enter into the menu interface.
1.Configuration
2.Data Calibration
3.Historical Records
4.Start/Stop Genset
5.About
Press Up/Down key to choose parameters (the current line was
highlighted with black) and then press Confirm key to enter into the
corresponding display screen.
NOTE：Default password is 01234, user can change it in case of others change the parameters
setting. Please clearly remember the password after changing. If you forget it, please contact SmartGen
services.
NOTE：Data Calibration is for factory use only and correct passwords must be input before entered.
