HAT700 SERIES ATS CONTROLLER USER MANUAL
HAT700 Series ATS Controller 2018-12-13 Version 1.5 Page 30 of 51
No.
Items
Description
26
S2 Unavailable
Output when S2 power is abnormal.
27
S1 Over Current
Output when S1 over current occurs.
28
S2 Over Current
Output when S2 over current occurs.
29
Reserved
30
Auto Mode
Output when the genset is in Auto mode.
31
Manual Mode
Output when the genset is in Manual mode.
32
Genset Start Output
Control the genset to start.
33
Reserved
34
S1 Close Control
Control the S1 switch to close.
35
S1 Open Control
Control the S1 switch to open. If PC Three-stage is selected, it also
control the S2 switch to open.
36
S2 Close Control
Control the S2 switch to close.
37
S2 Open Control
Control the S2 switch to open.
38
Reserved
39
Reserved
40
NEL1 Trip
Control the NEL off load when the output is active; It can control the
NEL on load again when the output deactivated.
41
NEL2 Trip
42
NEL3 Trip
43
Reserved
44
Reserved
45
Breaker1 On Feedback
The close status of S1 switch
46
Breaker2 On Feedback
The close status of S2 switch
47
S1 Genset Start
When the system type is “S1 Gen S2 Gen”, it controls the S1
genset start.
48
S2 Genset Start
When the system type is “S1 Gen S2 Gen”, it controls the S2
genset start.
49
ATS Power L1
ATS power supply
50
ATS Power L2
51
ATS Power L3
52
ATS Power N
53
Remote Control
Control the output via RS485 command.
54
Input 1 Status
Input status
55
Input 2 Status
56
Input 3 Status
57
Input 4 Status
58
Reserved
59
Reserved
60
Reserved
61
Reserved
62
Reserved
63
Reserved
64
S1 Blackout
S1 power supply status
65
S1 Over Volt
66
S1 Under Volt
