HGM400 Series Genset Controller ISSUE 2015-05-27 Version 1.6 Page 21 of 44
Pin
Function
Cable
Size
Description
active (B-); Can be used
as Config. Sensor.
11
Engine Temperature
Sensor
1.0mm
2
Connect to
temperature/cylinder
resistance sensor.
See Table 4
12
Oil Press Sensor
1.0mm
2
Connect to oil pressure
resistance sensor.
13
Current IA
1.5mm
2
Outside connected to secondary coil of
current transformer(rated 5A)
14
Current IB
1.5mm
2
Outside connected to secondary coil of
current transformer(rated 5A)
15
Current IC
1.5mm
2
Outside connected to secondary coil of
current transformer(rated 5A)
16
Current COM
1.5mm
2
See INSTALLATION in this manual.
17
Magnetic Pickup
0.5mm
2
Connect to speed sensor;
Shielded wire is recommended.
The other end of speed sensor connects
to B-.
18
Charger D+
1.0mm
2
Connect to charging starter’s D+
terminal. If there is no this terminal, then
be hang up.
19
Aux. Output 4
1.0mm
2
The combination of terminal 19 and 21 is
relay normally open contact; rated 5A;
Voltage free.
20
Aux. Output 5
1.0mm
2
The combination of terminal 20 and 21 is
relay normally open contact; rated 5A;
Voltage free.
21
Aux. Output COM
1.5mm
2
Common terminal of auxiliary output 4
and 5.
22
Gen AC Voltage U
1.0mm
2
Connected to U-phase of generator (2A
fuse is recommended)
23
Gen AC Voltage V
1.0mm
2
Connected to V-phase of generator (2A
fuse is recommended)
24
Gen AC Voltage W
1.0mm
2
Connected to W-phase of generator (2A
fuse is recommended)
25
Gen AC Voltage N2
1.0mm
2
Connected to N-wire of generator.
26
Mains AC Voltage R
1.0mm
2
Connected to R-phase of mains (2A fuse
is recommended) (HGM410 without)
27
Mains AC Voltage S
1.0mm
2
Connected to S-phase of mains (2A fuse
is recommended) (HGM410 without)
28
Mains AC Voltage T
1.0mm
2
Connected to T-phase of mains (2A fuse
