Smartgen HGM400 Series User Manual

HGM400 Series Genset Controller User Manual
HGM400 Series Genset Controller ISSUE 2015-05-27 Version 1.6 Page 26 of 44
No
Items
Range
Default
Description
29
Low Oil Pressure
(0-400)kPa
103
When the external pressure
sensor value falls below this set
value, “Low Oil Pressure” timer is
initiated. Detecting only after
safety on delay has expired. If
the set value is 0, low oil
pressure signal will not be sent
(this only concerns pressure
sensor and does not concern low
oil pressure warning signal via
configurable input port)
30
Low Fuel Level
(0-100)%
10
When the liquid level of the
external sensor falls below the
set value, “Low Fuel Level” timer
is initiated. (this only concerns
fuel level sensor and does not
concern low fuel level warning
signal via configurable input port)
31
Config. Sensor
(80-140)ºC
(0-400)kPa
(0-100)%
98
103
10
Each value correspond to above
28 (Temperature sensor), 29 (Oil
pressure sensor) and 30 (Level
sensor), respectively.
32
Loss of Speed
Signal
(0-20.0)s
5.0
If the set value is 0, only warning
and not to shutdown the
generator.
33
Charge Alt Failure
(0-30)V
6.0
During generator is normal
running, when alternator D+(WL)
voltage has fallen below the set
value and remains for 5s, It will
initiate a shutdown alarm signal.
34
Battery Over
Voltage
(12-40)V
33.0
When battery voltage has
exceeds the set value and
remains for 20s, It will initiate a
warning alarm signal. Only
warning and not to shutdown the
generator.
35
Battery Under
Voltage
(4-30)V
8.0
When battery voltage has fallen
below the set value and remains
for 20s, It will initiate a warning
alarm signal. Only warning and
not to shutdown the generator.
