HGM400 Series Genset Controller User Manual
HGM400 Series Genset Controller ISSUE 2015-05-27 Version 1.6 Page 27 of 44
No
Items
Range
Default
Description
36
Current Trans.
(5-6000)/5
500
The ratio of external CT
37
Full Load Current
Rating
(5-6000)A
500
Generator’s rated current, used
for load over current calculating.
38
Over Current
Percentage
(50-130)%
120
When the load current has
exceeded the set value, “over
current” delay is initiated.
39
Over Current
Delay
(0-3600)s
1296
When load current has exceeded
the set value and the “over
current” delay has expired, over
current alarm is initiated. When
the set value is 0, only warning
and not to shutdown the
generator.
40
Fuel Pump On
(0-100)%
25
When fuel level has fallen below
the set value for 10s, “Fuel Pump
On” alarm is initiated.
41
Fuel Pump Off
(0-100)%
80
When fuel level has exceeded
the set value for 10s, “Fuel Pump
Off” alarm is initiated.
42
Aux. Output 1
(0-17)
14
Factory default: Fuel Relay
Output
43
Aux. Output 2
(0-17)
2
Factory default: Energized To
Stop
44
Aux. Output 3
(0-17)
3
Factory default: Idle Control
45
Aux. Output 4
(0-17)
5
Factory default: Close Generator
46
Aux. Output 5
(0-17)
6
Factory default: Mains Closed
47
Aux. Input 1
(0-15)
1
Factory default: High
Temperature Input
48
Aux. Input 1
Active
(0-1)
0
Factory default: Close to active
49
Aux. Input 1
Delay
(0-20.0)s
2.0
50
Aux. Input 2
(0-15)
2
Factory default: Low Oil Pressure
Warning Input
51
Aux. Input 2
Active
(0-1)
0
Factory default: Close to active
52
Aux. Input 2
Delay
(0-20.0)s
2.0
53
Aux. Input 3
(0-15)
10
Factory default: Remote Start
54
Aux. Input 3
Active
(0-1)
0
Factory default: Close to active
