HGM400 Series Genset Controller ISSUE 2015-05-27 Version 1.6 Page 28 of 44
No
Items
Range
Default
Description
55
Aux. Input 3
Delay
(0-20.0)s
2.0
56
Aux. Input 4
(0-15)
11
Factory default: Fuel Level Warn
57
Aux. Input 4
Active
(0-1)
0
Factory default: Close to active
58
Aux. Input 4
Delay
(0-20.0)s
2.0
59
Power On Mode
(0-2)
0
0: Stop Mode
1: Manual Mode
2: Auto Mode
60
Module Address
(1-254)
1
Communication address of
controller.
61
Passwords
(0-9999)
1234
62
Crank Disconnect
(0-5)
2
There are 3 conditions of
disconnecting starter with engine:
Generator Frequency, Magnetic
Pickup, Oil Pressure. Each
condition can be used alone and
simultaneously to separating the
start motor and genset as soon
as possible.
See Table 5
63
Disconnect
Magnetic Pickup
(0-3000)RPM
360
When engine speed higher than
the set value, starter will be
disconnected.
64
Disconnect
Generator Freq
(10.0-30.0)Hz
14.0
When generator frequency
higher than the set value, starter
will be disconnected.
65
Disconnect Oil
Pressure
(0-400)kPa
200
When generator oil pressure
higher than the set value, starter
will be disconnected.
66
High Temperature
Inhibit
(0-1)
0
Factory default: when high
temperature occurs, shutdown
alarm is initiated. Note 1
67
Low Oil Pressure
Inhibit
(0-1)
0
Factory default: when low oil
pressure occurs, shutdown alarm
is initiated. Note 2
68
Low Fuel Level
Inhibit
(0-1)
1
Factory default: when low fuel
level occurs, shutdown alarm is
initiated. Note 2
