HGM400 Series Genset Controller User Manual
HGM400 Series Genset Controller ISSUE 2015-05-27 Version 1.6 Page 29 of 44
No
Items
Range
Default
Description
69
Config. Sensor
Inhibit
(0-1)
1
Factory default: when config.
sensor value higher/lower than
the set value (particular case
depends on the sensor type),
shutdown alarm is initiated.
Note 2
70
AC System
(0-3)
0
0: 3P4W; 1: 2P3W
2: 1P2W; 3: 3P3W Note 3
71
Temp. Sensor
Curve
(0-9)
08
SGX
72
Pressure Sensor
Curve
(0-9)
08
SGX
73
Multiplex Input 1
(0-1)
0
0: Aux. Input 3
1: Level Sensor Note 4
74
Level Sensor
Curve
(0-5)
3
SGD
75
Multiplex Input 2
(0-3)
0
0: Aux. Input 4
1: Temperature Sensor
2: Oil Pressure Sensor
3: Level Sensor Note 4
76
Config. Sensor
Curve
(0-9)
(0-9)
(0-5)
8
8
3
SGX
SGX
SGD
77
Poles
(2-32)
4
78
Temperature
Sensor Open
(0-2)
1
0: Indication (temperature sensor
will show “+++”);
1:Warn; 2:Shutdown
79
Oil Pressure
Sensor Open
(0-2)
1
0: Indication (oil pressure sensor
will show “+++”);
1:Warn; 2:Shutdown
80
Fuel Level Sensor
Open
(0-2)
1
0: Indication (fuel level sensor will
show “+++”);
1:Warn; 2:Shutdown
81
Config. Sensor
Open
(0-2)
1
0: Indication (LCD display will
show “+++”);
1:Warn; 2:Shutdown
82
Cooling Blower
On
(0-140)℃
60
It controls the cooling blower to
open or close if the output port is
configured as Cooling Blower.
83
Cooling Blower
Off
(0-140)℃
40
