HGM6100N Series Genset Controller User Manual Page 21 of 47
No.
Items
Range
Default
Description
31(26)
Loss of Speed Signal
Delay
(0-20.0)s
5.0
When the delay setting as 0s, it only warn but
not shutdown.
32(27)
Charging Failure Volt.
Difference
(0-30)V
6.0
During genset normal running, when B+ and
charger D+ (WL) voltage difference is above
this value for 5s, the controller issues
“Charging Failure” warning.
33(28)
Battery Over Voltage
(12-40)V
33.0
When generator battery voltage is over the
point and remains for 20s, battery over
voltage signal is active. it only sends warn but
not shutdown.
34(29)
Battery Under Voltage
(4-30)V
8.0
When generator battery voltage is under the
point and remains for 20s, battery under
voltage signal is active. it only sends warn but
not shutdown.
35(30)
CT Ratio
(5-6000)/5
500
External current transformer ratio.
36(31)
Full Load Rating
(5-6000)A
500
Rated current of generator, used for
calculating over load current.
37(32)
Over Current
Percentage
(50-130)%
120
When load current is over the point, the over
current delay is initiated.
38(33)
Over Current Delay
(0-3600)s
30
When load current is over the point, over
current signal is sent. When the delay is 0,
only warn but not shutdown.
39(34)
Fuel Pump On
(0-100)%
25
When the fuel level lower than the set value
for 10s, it sends a signal to open fuel pump.
40(35)
Fuel Pump Off
(0-100)%
80
When the fuel level higher than the set value
for 10s, it sends a signal to close fuel pump.
41(36)
Aux. Output 1
(0-26)
2
Factory default:
Energized to stop. See
table 8.
HGM6100N
parameter range:
(0-25).
42(37)
Aux. Output 2
(0-26)
3
Factory default: Idle
control. See table 8.
43(38)
Aux. Output 3
(0-26)
5
Factory default: Gens
closed. See table 8.
44(39)
Aux. Output 4
(0-26)
6
Factory default: Mains
closed. See table 8.
45(40)
Aux. Input 1
(0-25)
1
Factory default: High temperature alarm. See
table 8.
46(41)
Active Type
(0-1)
0
Factory default: close.
47(42)
Delay
(0-20.0)s
2.0
48(43)
Aux. Input 2
(0-25)
2
Factory default: Low oil pressure alarm. See
table 9.
49(44)
Active Type
(0-1)
0
Factory default: close.
