Remote + Motor Pairing
Each battery motor will come preprogramed from Smartwings .
The preprograming ensures the remote is paired with the motor, the upper and lower operation limits
are set, the remote is unlocked.
Follow the below steps to select the remote channel you want to pair with the motor(s) if required at a
later date.
Press any
button to
wake remote
Within 10sec Press
" "
or " " to
select desired
channel.
1a
1b
1. SELECT CHANNEL
Within 10 sec of
activating pairing mode,
Press & Hold STOP
If you do not pair the remote in time the motor pairing sequence will time out, repeat the
above steps assuring to press and hold the STOP button within 10 seconds of the motor jog
2. PAIRING REMOTE TO MOTOR
Press & HOLD
Programming Button
on motor head (2sec)
2a ACTIVATE PAIRING MODE ON MOTOR
2b ADDING OR REMOVING THE REMOTE
Note: the motor jogs once
Note: t
he motor jogs twice
.
Press STOP (2sec)
To Next Page
