Communication specifications
Item Specifications
Protocol Ethernet (IEEE802.3)
Transmission medium
Standard Ethernet cable (CAT5 or more)
(100BASE
- TX)
Transmission speed 10 Mbps / 100 Mbps (Auto negotiation)
Transmission method Full duplex / Half duplex (Auto negotiation)
Fieldbus protocol
EtherNet/IP
TM
Volume1 (Edition 3.8)
Volume2 (Edition 1.9)
Vendor ID 7h (SMC Corporation)
Product type 1Bh (Pneumatic Valve)
Product code
9Ch: EX260-SEN1
9Dh: EX260-SEN2
9Eh: EX260-SEN3
9Fh: EX260-SEN4
Network topology
Star: Applicable
Linear Bus: Applicable
Ring:
Not applicable
DLR:
Not applicable
IP address setting range
Manual setting using switches in SI unit:
192.168.0.1 to 254 or 192.168.1.1 to 254
Via DHCP server: Arbitrary address
Configuration file
EDS file
(Please download from the SMC website)
Occupied area
(number of inputs / outputs)
EX260-SEN1/-SEN2: 16/32
EX260-SEN3/-SEN4: 16/16
Connectable valve series
Valve Series
SY series SY3000, SY5000
VQC series VQC1000, VQC2000, VQC4000
SV series SV1000, SV2000, SV3000 (10 type tie-rod base)
S0700 series S0700
∗: The valve manifolds that can be connected are the same as those connectable to EX250 series.
