Specifications
■Specifications
General specifications
Item Specifications
Ambient temperature - 10 to +50
o
C
Ambient humidity 35 to 85%RH (No condensate)
Ambient temperature for storage - 20 to +60
o
C
Withstand voltage 500 VAC applied for 1 minute
Insulation resistance 500 VDC, 10 MΩ or more
Operating atmosphere No corrosive gas
Pollution degree Pollution degree 3
Enclosure IP67
Weight 200 g or less
Electrical specifications
Item Specifications
Current consumption of controller
power supply
21.6 to 26.4 VDC
0.1 A max.
Current
consumption in
power supply
voltage range
Solenoid valve power supply
22.8 to 26.4 VDC
2.0 A or less, according to the solenoid valve station
specification
EX260-SEN1/-SEN3 PNP (negative common) / source
Output type
EX260-SEN2/-SEN4 NPN (positive common) / sink
EX260-SEN1/-SEN2 32 outputs
Number of
outputs
EX260-SEN3/-SEN4 16 outputs
Output condition at the time of
communication error
Output HOLD/CLEAR
Connected load
Solenoid valve with surge voltage suppressor of
24 VDC and 1.5 W or less (manufactured by SMC)
Insulation type Photo coupler insulation type
Solenoid valve
connecting
specification
Residual voltage 0.4 VDC or less
