-33-

No.EX##-OMP0013-A
○I/O Mapping
Input area mapping
Input data
MSB LSB MSB LSB
Offset
(Word)
15 8 7 0
0 L L L L SOLV L L L L L L L L L L L
L: Low fixed (0)
Input status area
Input status area specifications
Item Status State
0 Normal
SOLV State of power supply for solenoid valve
1 Abnormal (19 V or less)
Output area mapping
•For EX260-SEN1/-SEN2
Output data
MSB LSB MSB LSB
Offset
(Word)
15 8 7 0
0 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
1 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
•For EX260-SEN3/-SEN4
Output data
MSB LSB MSB LSB
Offset
(Word)
15 8 7 0
0 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
