-47-
No.EX##-OMN0036
•EX600-DM F
No. Description Function
1
Status display LED Displays the status of the unit.
2
Connector (I
/O
)
Connector for input and output devices.
3
Marker groove Groove to mount a marker.
4
Joint bracket Bracket for joining to adjacent units.
5
Unit connector (Plug) Transmits signals and power supplies to adjacent units.
