A
BOUT
THE
T
IGER
S
WITCH
10/100
1-4
TigerSwitch 10/100 fiber port
The fiber connector available on the TigerSwitch 10/100 is an SC
multi-mode connector. It is listed in the below figure.
System Status LEDs
LED Status Color Description
Power On Green Power On
10/100 On Green This port is operating at the speed of
100Mbps
Off In 10Mbps mode or no device attached
Link/
Act
On Green This port is successfully connecting with
the device
Blinks Green The port is receiving or transmitting data
Off No device attached
FDX/
COL
On Orange This port is operating in Full-duplex mode
Blinks Orange Collision of packets occurs in the port
Off Half-duplex mode or no device attached
10/100
9
TigerSwitch 10/100
6709FL2
