C-1
A
PPENDIX
C
S
PECIFICATIONS
Physical Characteristics
Ports
8 10BASE-T/100BASE-TX ports, with auto-negotiation
1 100BASE-FX port
1 Console port
Network Interface
Ports 1-8: RJ-45 connector, auto MDI/MDI-X
10BASE-T: RJ-45 (100-ohm, UTP cable; Categories 3, 4, 5)
100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5)
Port 9: Fiber SC connector
100BASE-FX MMF: SC connector (62.5/125 or 50/125 microns-
-cable)
Buffer Architecture
2 Mbits
Aggregate Bandwidth
1.8 Gbps
Switching Database
8K MAC address entries
LEDs
System: Power
Port: 10/100, Link/Act, FDX/COL
Weight
1.18kg (2.6 lbs)
