SMC Networks TigerSwitch SMC6709FL2 Installation Guide

C ONSOLE P ORT P IN A SSIGNMENTS
B-5
Console Port to 25-Pin DTE Port on PC
Switch’s 9-Pin
Serial Port
Null Modem PC’s 25-Pin
DTE Port
2 RXD <---------RXD ------------ 2 TXD
3 TXD -----------TXD ----------> 3 RXD
5 SGND -----------SGND ---------- 7 SGND
No other pins are used.
