-37-

No.PS※※-OML0003-J

■Special function setting

■[F90] Setting of all functions

All functions can be set, one after the other.

Press the

or button in function selection mode to display [F90].

Press the button. Move on to setting of all functions.

[oFF] (unused)

selected.

Press the

button

to set.

Return to function

selection mode.

[on] (used) selected

Setting of each function

∗

After the change to [oFF] (unused),

press the button to set.

Return to function selection mode.

Press the

button for 2

seconds or longer.

[F90] Setting of all functions completed Measurement mode

∗1: Setting of functions

Every time the

button is pressed, the function steps in the order of Function setting on page 38.

Set using the

or buttons.

Refer to each section for further details of the setting.

Setting of all functions

Press the

button to select all functions.
