Specifications
Model No.
ZSE30A
(vacuum)
ZSE30AF
(compound)
ISE30A
(positive pressure)
Rated pressure range
0.0 to -101.0 kPa
-100.0 to 100.0 kPa
-0.100 to 1.000 MPa
Set pressure range 10.0 to -105.0 kPa -105.0 to 105.0 kPa -0.105 to 1.050 MPa
Withstand pressure 500 kPa 500 kPa 1.5 MPa
Minimum display unit 0.1 kPa 0.1 kPa 0.001 MPa
Applicable fluid
Air, inert gases and incombustible gases
Power supply voltage 12 to 24 VDC ±10%, ripple (p-p) 10% or less (protected against reverse connection)
Current consumption 40 mA or less
Switch output
NPN or PNP open collector output : 1 output
NPN or PNP open collector output : 2 outputs (selectable)
Max. load current 80 mA
Max. applied voltage 28 V (NPN output)
Residual voltage 1 V or less (at 80 mA load current)
Response time
2.5 ms or less
(with anti-chatter function: 20, 100, 500, 1000 or 2000 ms selected)
Short circuit protection Provided
Repeatability ±0.2%F.S. ±1 digit
Hysteresis
Hysteresis mode
0 to variable
∗1
Window comparator mode
Analogue output
Voltage output
∗
2
Output Voltage
(rated pressure range)
1 to 5 V ±2.5%F.S.
0.6 to 5 V
±2.5%F.S.
Linearity ±1%F.S.
Output impedance
approx. 1 k
Ω
Current output
∗3
Output current
(rated pressure range)
4 to 20 mA ±2.5%F.S.
2.4 to 20 mA
±2.5%F.S.
Linearity ±1%F.S.
Load impedance
Max. load impedance: 300 Ω (at power supply voltage of 12 VDC)
600 Ω (at power supply voltage of 24 VDC)
Min. load impedance: 50 Ω
Display 4 digits, 7-segment, dual-colour display (red/green)
Display accuracy
±2%F.S. ±1digit (at ambient temperature 25±3 °C)
Indicator LED LED is ON when output is ON OUT1: Green OUT2: Red
Environment
Enclosure IP40
Ambient temperature range
Operation: 0 to 50 °C, Storage: -10 to 60 °C (no condensation or freezing)
Ambient humidity range Operation, Storage: 35 to 85%RH (no condensation)
Withstand voltage 1000 VAC, 1 minute between terminals and housing
Insulation resistance
50 MΩ or more at 500 VDC between terminals and housing
Temperature characteristics
±2%F.S. (25 °C reference)
Lead wire
Oil resistant vinyl cabtyre cable
3 cores φ3.5, 2 m
4 cores Sectional area of conductor: 0.15 mm
2
(AWG26)
Outside diameter of insulator: 1.0 mm
Standard CE marked (EMC directive, RoHS directive), UL/CSA
∗1: If the applied voltage fluctuates around the set value, the hysteresis must be set to more than the fluctuation width. Otherwise,
chattering will occur.
∗2: If analogue voltage output is selected, the analogue current output cannot be selected.
∗3: If analogue current output is selected, the analogue voltage output cannot be selected.
