Snap-On PLASMA60i User Manual

6
DESCRIPTION OF EQUIPMENT
A Power cor d
B Compressed air fitting (1/4" female gas thread)
C Main power switch “0” = off “l” = on
D Main power led
E Pressure regulator knob (Lift to adjust)
F Pressure gauge
G Thermostat LED
H Ground cor d
I Water trap
L Low air pressure LED
M Cutting current regulator knob
N Blocked LED; lights when hazardous conditions arise.
O LED that lights when the "SELF-RESTART PILOT"
function is active
P Push-button to activate and deactivate the
"SELF- RESTART PILOT" function.
Q Plasma tor ch (includes consumable parts).
Q

Snap-On PLASMA60i Specifications
