Chapter 2 – Specications
6 S1930E/S1932E/S2632E – 1360460
General Specications – S2632E
Aerial Platform
Working height 32′ 3″ (9.8 m)
Maximum platform height 26′ 3″ (8 m)
Turning radius
Inside 10″ (25.4 cm)
Outside 92″ (234 cm)
Wheelbase 6′ 4″ (1.92 m)
Ground clearance
Pothole protector raised 2.5″ (6.3 cm)
Pothole protector lowered 0.75″ (1.9 cm)
Maximum wheel load 2,450 lbs (1,112 kg)
Maximum ground pressure 190 psi (430 kg/cm²)
Weight, EVW
Approximate 4,900 lbs (2,224 kg)
Stowed width 32″ (81.3 cm)
Stowed length 93.25″ (2.37 m)
With step removed 93.25″ (2.37 m)
Stowed height
Rails up 91.63″ (2.33 m)
Rails down 76″ (1.93 m)
Platform
Dimensions
Main 29″ x 91″ (74 cm x 231 cm)
Extension 24″ x 36″ (61 cm x 91.4 cm)
Total length with extension 127″ (322.6 cm)
Guardrail height
Rails up 44″ (111.8 cm)
Rails down 24.5″ (62.2 cm)
Toeboard height 6″ (15.2 cm)
Rated work load
Total 500 lb (227 kg)
Extension 250 lb (113.3 kg)
Maximum number of occupants 1 outdoors
2 indoors
Function Speed
Platform raise 12 to 20 seconds
Platform lower 20 to 26 seconds
High Drive
Platform lower than 6′ (1.8 m)
0 to 2 mph (0 to 3.2 km/h)
Low Drive
Platform higher than 6′ (1.8 m)
0 to 0.4 mph (0 to 0.6 km/h)
Drive System
Standard Two-wheel drive
Gradeability 25%
Maximum drive height 26′ 3″ (8 m)
Drive/Lift Level Sensor Interlock
Side-to-side 2 degrees
Front-to-rear 4 degrees
Tires
Nonmarking solid rubber 15″ x 5″ (38.1 cm x 12.7 cm)
Electrical System
Voltage 24 V DC negative chassis ground
Source Four - 6 V 220 amp hour batteries
Fluid recommended distilled water
Charger 25 amp
Hydraulic System
Maximum pressure 3,000 psi (20,684 kPa)
Reservoir capacity 6.8 US gal (25.7 l)
System capacity 7.3 US gal (27.6 l)
Maximum operating temperature 160°F (71°C)
Hydraulic uid recommended
Above 10°F (-12°C) ISO VG32 (Mobil DTE 10 XL32)
Below 10°F (-12°C) ISO VG15 (Mobil DTE 10 XL15)
Ambient Air Temperature Operating Range
Fahrenheit 0°F to 110°F
Celsius -18°C to 43°C
Maximum Wind Speed
Gust or steady 28 mph (12.5 m/s)
