Chapter 2 – Specications
Component Identication
Toeboards
Scissors
Structure
Right Side
Platform
Guardrails
Left Side
Lower
Controls
Operator’s
Manual
Chassis
Entry
Step
Upper
Controls
Entry
Gate
Battery Charge
Indicator
Tie-Down Lugs
Battery Tray
Batteries • Charger Plug • Battery Disconnect
Platform Extension
Hydraulic Tray
Hydraulic Reservoir • Hydraulic Fluid Filter
Wallboard
Loading Gate
Rear
Front
Lifting Lugs
Forklift Pockets
Drive and Steer
Wheels
Pothole Protector Skid
Drive and Steer
Wheels
Groundstrap
Emergency
Lowering Lever
S1930E/S1932E
Serial
Number
Tie-Down/Lifting
Lugs
Emergency
Lowering Handle
S2632E
