UpStreamVoltage
20751 510F 1 Source 1: F Hz/100
20752 5110 1 Source 2: U12 V/100
20753 5111 1 Source 2: U23 V/100
20754 5112 1 Source 2: U31 V/100
20755 5113 1 Source 2: V1 V/100
20756 5114 1 Source 2: V2 V/100
20757 5115 1 Source 2: V3 V/100
20758 5116 1 Source 2: F Hz/100
DownStreamCurrent
20759 5117 1 I1 mA
20760 5118 1 I2 mA
20761 5119 1 I3 mA
20762 511A 1 Ineutral mA
Power
20763 511B 2 Active Power phase 1 W / 100
20765 511D 2 Active Power phase 2 W / 100
20767 511F 2 Active Power phase 3 W / 100
20769 5121 2 Reactive Power phase 1 var / 100
20771 5123 2 Reactive Power phase 2 var / 100
20773 5125 2 Reactive Power phase 3 var / 100
20775 5127 2 Apparent power phase 1 VA / 100
20777 5129 2 Apparent power phase 2 VA / 100
20779 512B 2 Apparent power phase 3 VA / 100
20781 512D 1 Power Factor phase 1
(-: leading and +: lagging)
% / 100
20782 512E 1 Power Factor phase 2
(-: leading and +: lagging)
% / 100
20783 512F 1 Power Factor phase 3
(-: leading and +: lagging)
% / 100
20784 5130 2 Total Active Power W / 100
20786 5132 2 Total Reactive Power var / 100
20788 5134 2 Total Apparent Power VA / 100
20790 5136 1 Total Power Factor
(-: leading and +: lagging)
% / 100
UpStreamStatus
20791 5137 1 Neutral position
0: Left
1: Right
20792 5138 1 Source 1: Single voltage unbalance % / 100
20793 5139 1 Source 1: Phases rotation
0: N/A
1: ABC
2: ACB
20794 513A 1 Source 2: Single voltage unbalance % / 100
20795 513B 1 Source 2: Phases rotation
0: N/A
1: ABC
2: ACB
