ATYSp - 542001E - SOCOMEC
Dec.
Address
Hex.
Address
Words
count
Description Unit
20511 501F 1 BET Mode
0: Not present
1: Auto
2: Manual
3: Remote control
4: Locked
20512 5020 1 BET Available
0: Not available
1: Available
20513 5021 1 Product is available
0: Not available
1: Available
AnnexeII-10.Engineexerciser-customtimerangestatus
Function 3 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
20560 5050 2 Date & Time current sec.
20562 5052 1 Next custom range to be activated
0: None
1: Custom 1
2: Custom 2
3: Custom 3
4: Custom 4
20563 5053 2 Next custom range start date sec.
20565 5055 2 Next custom range stop date sec.
20567 5057 2 Next custom range start delay sec.
AnnexeII-11.Measurementtable(noCT/VTaffected)
Function 3 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
20736 5100 2 Date & Time current sec.
DownStreamVoltage
20738 5102 1 U12 V/100
20739 5103 1 U23 V/100
20740 5104 1 U31 V/100
20741 5105 1 V1 V/100
20742 5106 1 V2 V/100
20743 5107 1 V3 V/100
20744 5108 1 Fr Hz/100
UpStreamVoltage
20745 5109 1 Source 1: U12 V/100
20746 510A 1 Source 1: U23 V/100
20747 510B 1 Source 1: U31 V/100
20748 510C 1 Source 1: V1 V/100
20749 510D 1 Source 1: V2 V/100
20750 510E 1 Source 1: V3 V/100
