ATYSp - 542001E - SOCOMEC
Dec.
Address
Hex.
Address
Words
count
Description Unit
21506 5402 1 Option slot 1 Type
0xFF: None
0x00: Communication option
0x01: Metering option
0x20: Input/Output option
0x30: Analog Outputs option
0x70: Ethernet option
21507 5403 1 Option slot 2 Type
0xFF: None
0x00: Communication option
0x01: Metering option
0x20: Input/Output option
0x30: Analog Outputs option
0x70: Ethernet option
21508 5404 1 Option slot 3 Type
0xFF: None
0x00: Communication option
0x01: Metering option
0x20: Input/Output option
0x30: Analog Outputs option
0x70: Ethernet option
21509 5405 1 Option slot 4 Type
0xFF: None
0x00: Communication option
0x01: Metering option
0x20: Input/Output option
0x30: Analog Outputs option
0x70: Ethernet option
AnnexeII-15.Commands
Function 6 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
21760 5500 1 Set Command / Alarm
0x01: Set RTE
0x02: Clear TOF
0x03: Set TOF
0x04: Set TON
0x05: Set EOF
0x06: Set EON
0x07: Clear EOF
0x08: Clear EON
0x10: Clear Alarms/Faults
0x11: Set External Fault 1
0x12: Set External Fault 2
0x13: Set External Alarm 1
0x14: Set External Alarm 2
21761 5501 1 Set Operating Mode
3: Auto
4: Inhibit
5: Remote Control
21762 5502 1 Set Priority
0: Network
1: Source 1
2: Source 2
21763 5503 1 Set Position
0: None
1: Position in Zero
2: Position in 1
3: Position in 2
