ATYSp - 542001E - SOCOMEC
Dec.
Address
Hex.
Address
Words
count
Description Unit
23059 5A13 1 In 14 function
(only with 2IN2OUT module #4)
0: --- - None
1: INH - Inhibition
2: TON - Test on load
3: TOF - Test off load
4: EON - External order on load
5: EOF - External order off load
6: RTC - Retransfer
7: PRI - Priority
8: SS1 - Validation Stabilization source 1
9: SS2 - Validation Stabilization source 2
10: AL1 - Alarm 1
11: AL2 - Alarm 2
12: FT1 - Fault 1
13: FT2 - Fault 2
14: MSR - Power priority
15: OA1 - Override source 1 available
16: OA2 - Override source 2 available
17: RST - Reset faults state
18: LSI - Load shedding
19: TR1 - Time Range1 Validate
20: TR2 - Time Range2 Validate
21: TR3 - Time Range3 Validate
22: TR4 - Time Range4 Validate
24: CHP - Change of position
23060 5A14 1 In 7 state
(only with 2IN2OUT module #1)
0: NO
1: NC
23061 5A15 1 In 8 state
(only with 2IN2OUT module #1)
0: NO
1: NC
23062 5A16 1 In 9 state
(only with 2IN2OUT module #2)
0: NO
1: NC
23063 5A17 1 In 10 state
(only with 2IN2OUT module #2)
0: NO
1: NC
23064 5A18 1 In 11 state
(only with 2IN2OUT module #3)
0: NO
1: NC
23065 5A19 1 In 12 state
(only with 2IN2OUT module #3)
0: NO
1: NC
23066 5A1A 1 In 13 state
(only with 2IN2OUT module #4)
0: NO
1: NC
23067 5A1B 1 In 14 state
(only with 2IN2OUT module #4)
0: NO
1: NC
