socomec ATyS r User Manual

139
EN
ATYSp - 542001E - SOCOMEC
Dec.
Address
Hex.
Address
Words
count
Description Unit
0 0 1 0x0707: Source 2 EA+ counter reset
0x0708: Source 2 EA- counter reset
0x0709: Source 2 EQ+ counter reset
0x070A: Source 2 EQ- counter reset
0x070B: Source 2 ES counter reset
0x070C: Source 2 Time meter reset
0x070D: Start order count reset
0x070E: Start order active duration reset
0x070F: Secondary source duration reset
0x0710: Secondary source active duration reset
0x0711: Source 1 load supplied duration reset
0x0712: Source 2 load supplied duration reset
0x0801: Load shedding request activated
0x0802: Load shedding request deactivated
0x0901: Conguration n°1 active
0x0902: Conguration n°1 validated
0x0903: Conguration n°1 active
0x0904: Conguration n°1 validated
0x0905: Conguration n°1 active
0x0906: Conguration n°1 validated
0x0907: Conguration n°1 active
0x0908: Conguration n°1 validated
0x1001: Read indus area failure
0x1002: Write indus area failure
0x1003: Read serial number failure
0x1004: Write serial number failure
0x1101: Customization load error
0x1102: BET in default
0x1103: BET not present
0x1104: Load context failure
0x1105: StartGen relay fault
0x1106: RTC fault
0x1107: Internal display board detection error
0x1108: External display board detection error
0x1109: 2IN/2OUT option module #1 no more detected
0x110A: 2IN/2OUT option module #2 no more detected
0x110B: 2IN/2OUT option module #3 no more detected
0x110C: 2IN/2OUT option module #4 no more detected
0x110D: External display detection error
0x110E: I2C Fault
1 1 1 Type
0: State
1: Edge
2: System
2 2 1 Severity
0: none
1: information
2: warning
3: default
3 3 1 Satus
0: non active
1: active
2: nished
3: new & checked
4: nished & checked
4 4 4 Start Date ms since 1 jan
2000
8 8 2 Duration ms
10 A 1 Cause -
11 B 2 Value 1 -
13 D 2 Value 2 -
