socomec COUNTIS ECi2 User Manual

7
COUNTIS ECi - Ref.: 538 470 A
INSTALLATION
Connection
The COUNTIS ECi meter can be mounted on a 35 mm rail (EN 60715TH35).
It must be used inside electrical cabinets.
0.6 Nm
5 mm
0.14 / 2.5 mm
2
0.14 / 2.5 mm
2
0.6 Nm
8 mm
0.2 / 6 mm
2
0.2 / 4 mm
2

+
-
0/4...20mA


R=120Ω
RS485
 Aux.: 110 … 400 Vac
120 … 300 Vdc
 Fus.: 0.5 A gG / BS 88 2A gG
 250Vac 3A Relay
30Vdc / 1A
Sensor
