MAN 06 033774 technical_guide_ DIRIS_A40_A41_C.doc40/Z41 - B 10/27
Changing the relay output N°1(addresses Hex. 22E) closed = 1 and opened = 0
Master frame to open the relay:
Slave
Function
Address
Address
Value
Value
CRC16
High-order
High-order
High-order
Low-order
05
06
02
2E
00
00
E9FF
Open
Stop motor
Example 2 : Changing the relay 1 status to give a 3 seconds order to initiate a process
(same function as a pushbutton). Normally open relay run mode.
DIRIS configuration (see instruction manual: 876 587):
Relay output 1 type = Out 1 A-Cd TYPE = Cd-t (temporised command)
Temporisation before return to rest state =Out 1 TEMPO 003 (3 seconds)
Relay status = Out 1 RELAY NO (Normally open)
Process
OFF
ON
Relay
0
0
1
Communication
Address 22E = 1
TEMPO
=
3s
9
10
DIRIS A40
OUT 1
