iPDU II-1202 (2-inlet models of the iPDU)
Model iPDU II -1202 -120V iPDU II -1202 -230V
Power Input
IEC320 C20 inlet * 2 pcs, 40 Amps (2 inlets
share 40 Amps)
Inlet-G1: 100-125 VAC 50/60 Hz, 20 A
Inlet-G2: 100-125 VAC 50/60 Hz, 20 A
IEC320 C20 inlet * 2 pcs, 32 Amps (2 inlet share
32 Amps)
Inlet-G1: 200-240 VAC 50/60 Hz, 16 A
Inlet-G2: 200-240 VAC 50/60 Hz, 16 A
Breaker Type & Qty
20 A
2 pcs
16 A
2 pcs
Power Output
Voltage: 100-125 VAC 50/60 Hz Voltage: 200-240 VAC 50/60 Hz
IEC320 C-13 * 12 pcs. Grouping 3 pcs outlet into 1 unit.
Inlet-G1 support outlet A~F
Inlet-G2 support outlet G~L
Loading: Max. 10 Amp each outlet or Max. 10 Amp total for Outlet A~C. Same as D~F, G~I, J~L
Dimensions and Weight
Size
1U rack: 436 (W) x 300 (D) x 44 (H) mm
17 (W) x 11.8 (D) x 1.7 (H) inches
Weight Approx: 4.2 kg or 9.26 lbs
Operating Environment
Temperature 0 °C ~ 50 °C
Input Frequency 10 ~ 80% non-condensed
Warranty
Two years
iPDU II-1201 (1-inlet models of the iPDU)
Model iPDU II -1201 -120V iPDU II -1201 -230V
Power Input
IEC320 C20 inlet * 1 pcs, 20 Amps
Inlet-G1: 100-125 VAC 50/60 Hz, 20 A
IEC320 C20 inlet * 1 pcs, 16 Amps
Inlet-G1: 200-240 VAC 50/60 Hz, 16 A
Breaker Type & Qty
20 A
2 pcs
16 A
2 pcs
Power Output
Voltage: 100-125 VAC 50/60 Hz Voltage: 200-240 VAC 50/60 Hz
IEC320 C-13 * 12 pcs. Grouping 3 pcs outlet into 1 unit.
Loading: Max. 10 Amp each outlet or Max. 10 Amp total for Outlet A~C. Same as D~F, G~I, J~L
Dimensions and Weight
Size
1U rack: 436 (W) x 300 (D) x 44 (H) mm
17 (W) x 11.8 (D) x 1.7 (H) inches
Weight Approx: 4.1 kg or 9.05 lbs
Operating Environment
Temperature 0 °C ~ 50 °C
Input Frequency 10 ~ 80% non-condensed
Warranty
Two years
6. APPENDIX
6.1. Specifi cations
The specifications for iPDU II-1202 (2-inlet models of the iPDU ) and iPDU II-1201 (1-inlet models of the iPDU) are listed as follows:
