To Next PageTo Next PageWhat does 'inverter temperature high' mean on my socomec ITYS?
If your Socomec UPS displays a high inverter temperature, the internal temperature of the UPS is too high. Check the ventilation of the UPS and the ambient temperature of the room.
How to fix a 'battery open' error on my socomec ITYS UPS?
If your Socomec UPS indicates a battery open issue, it could mean that the battery pack is not connected correctly. Perform a battery test to confirm. Check that the battery bank is properly connected to the UPS and that the battery breaker is turned on.
What does line voltage high (OVCD action) mean on my socomec ITYS?
If your Socomec UPS indicates a high line voltage (OVCD action), the input power voltage is too high. The system will automatically switch to battery mode. Once the mains power returns to normal, the UPS should switch back to line mode automatically.
Why does my Socomec UPS have no indication even when connected to mains?
If your Socomec UPS has no indication or warning tone even when connected to the mains power supply, the issue might be due to no input voltage. Check the building wiring socket outlet and the input cable.
What causes shorter backup time on socomec ITYS UPS?
If the backup time of your Socomec UPS is shorter than the nominal value, the batteries may not be fully charged or may be defective. Charge the batteries for at least 5 - 8 hours and then check their capacity.
Why does my Socomec UPS display battery mode and alarm sounds every 4 seconds?
If your Socomec UPS displays battery mode and an alarm sounds every 4 seconds, it means the mains power supply has failed or the input power and/or frequency are outside of the acceptable limits. The system has automatically switched to battery mode. Check the input power source.
What to do if socomec ITYS UPS shows power overload?
If your socomec UPS indicates a power overload, it means the power requirements of the connected equipment exceed the UPS capacity (more than 105% of nominal). To resolve this, disconnect some equipment from the UPS. The alarm will reset once the overload condition is no longer present.
What to do if my socomec ITYS stalls or goes into overload alarm?
If your Socomec UPS stalls or goes into overload alarm, it indicates an overload on the load line. Verify that the load applied does not exceed the maximum permitted level. If it does, reduce the power requirement of the load.
Why is the backup time on my socomec ITYS shorter than expected?
If the backup time of your Socomec UPS is shorter than expected, it might be because the batteries are not fully charged. Allow the batteries to charge for 8 consecutive hours. If the issue persists, the batteries may not be working correctly and should be replaced by authorized personnel.
Why is my socomec ITYS UPS in battery mode when mains power is on?
If your Socomec UPS is running on battery even when mains power is available, it could be due to a poor connection to the input mains. Check the cable connection to both the UPS and the mains outlet. Alternatively, the input protection might have been triggered, such as a blown fuse or an automatic switch. If this is the case, replace the fuse with one of the same type or reset the automatic switch.
Details the warranty terms for repairs and replacements, including return shipping responsibilities.
Outlines the steps required to claim service under warranty, including required documentation.
Specifies warranty coverage for batteries and software products, including limitations.
Crucial safety advice for operating the UPS, including electrical hazards and battery handling.
Safety measures and installation restrictions applicable to 1-3 kVA models.
Safety measures and installation restrictions applicable to 6-10 kVA models.
Explains the meaning of warning symbols and labels found on the UPS unit.
Specifies optimal ambient temperature, humidity, and ventilation for UPS installation.
Provides instructions on unit placement, clearance, and connections for installation.
Details required input protection, leakage current limits, and cable sizing.
Illustrates the rear panel ports and connectors for ITYS 1 and 2 kVA models.
Illustrates the rear panel ports and connectors for the ITYS 3 kVA model.
Critical safety precautions to observe before connecting external battery modules.
Step-by-step instructions for correctly connecting the battery extension cable.
Explains the visual indicators, status displays, and control buttons on the UPS front panel.
Describes the different operating modes like Normal, Battery, Eco, and Converter modes.
Instructions on how to charge the internal UPS batteries for optimal performance.
Step-by-step guides for safely powering the UPS unit on and off.
Explains how to initiate and perform a battery health test.
Details how to navigate and configure UPS settings through the menu interface.
Lists and explains visual and audible alarms, fault codes, and warnings displayed by the unit.
How to connect the UPS to a computer using the USB interface for monitoring.
Information on using optional Web/SNMP cards for remote network management.
Details on establishing serial communication via the RS232 port for UPS control.
Addresses common operational issues like UPS on battery mode or short backup times.
Troubleshooting issues related to the mimic panel display, alarms, and audible warnings.
Diagnosing problems related to fans, temperature, voltage, and internal component failures.
Addresses common system errors like EEPROM, EPO, bypass, softstart, and battery connection issues.
Diagnoses problems related to battery levels, overload, fan, charger, and temperature issues.
Focuses on troubleshooting overload conditions, short circuits, and critical system faults.
Covers issues related to power indication, bypass LEDs, battery LEDs, and backup time indicators.
Comprehensive technical data including electrical, environmental, and mechanical characteristics.
Specific electrical safety requirements and parameters for the 6-10 kVA UPS models.
Illustrates the rear panel ports and connectors for the ITYS 6 kVA unit.
Illustrates the rear panel ports and connectors for the ITYS 10 kVA unit.
Visual guides showing how to make the necessary electrical connections for the UPS.
Critical safety precautions to observe before connecting external battery modules.
Step-by-step instructions for correctly connecting the battery extension cable.
Explains the status indicators, alarms, and control buttons on the UPS front panel.
Procedures for safely powering the UPS unit on.
Procedures for safely powering the UPS unit off.
Explains the different operational modes like Line, Battery, Eco, Converter, and Bypass.
Presents the hierarchical structure of the UPS's setting menu for configuration.
Describes how to activate and use the manual bypass feature for maintenance purposes.
Explains the procedure for safely returning the UPS from manual bypass to normal operating mode.
Explains the meaning of indicators, alarms, and their conditions displayed on the mimic panel.
How to connect the UPS to a computer using the USB interface for monitoring.
Information on using optional Web/SNMP cards for remote network management.
Details on establishing serial communication via the RS232 port for UPS control.
Pin assignments and descriptions for the dry contact interface for external signaling.
Comprehensive technical data including electrical, environmental, and mechanical characteristics for higher capacity models.
General| Frequency | 50/60 Hz |
|---|---|
| Input Voltage | 230 VAC |
| Output Voltage | 230 VAC |
| Form Factor | Tower |
| Power Factor | 0.9 |
| Operating Temperature | 0 to +40 °C |
| Communication Interface | USB, RS232 |
| Protection | short circuit protection |
| Topology | Line Interactive |
| Battery Type | Sealed Lead-Acid (SLA) |
| Noise Level | < 45 dBA (depending on model) |
