17EN
MASTERYS BC+ 10-40 kVA - IOMMASBCXX0G-EN 02 - SOCOMEC
• Separated input mains
Activating UPS protection on the mimic panel: access the MAIN MENU > SERVICE > UPS SETTINGS > MAINS
CONFIGURATION > MAINS / AUXILIARY and set the parameter to SEPARATED.
3/3 models
COM2
L1
X10
X40
L2
L3
N
L1
L2
L3
N
L1
L2
L3
N
L1
L2
L3
N
NC2
NO2
NO1
COM1
NC1
B
B
1
3
4
2
KEY
1
Distribution panel
2
UPS
B Trip coil
X10 Mains terminal
X40 Auxiliary Mains terminal
3
Mains switch
4
Auxiliary Mains switch
COM2 - NO2 Mains BKF connector
COM1 - NO1
Auxiliary Mains BKF connec-
tor
UPS output voltage
3/1 models
COM2
L1
X10
X40
L2
L3
N
L1
L2
L3
N
L1
N
L1
N
NC2
NO2
NO1
COM1
NC1
B
B
1
3
4
2
KEY
1
Distribution panel
2
UPS
B Trip coil
X10 Mains terminal
X40 Auxiliary Mains terminal
3
Mains switch
4
Auxiliary Mains switch
COM2 - NO2 Mains BKF connector
COM1 - NO1
Auxiliary Mains BKF connec-
tor
UPS output voltage
