38 EN
MODBUS RTU / MODBUS TCP for Modulys GP 2.0 - ITYS PRO UPS - Masterys GP4 UPS - Masterys BC+ UPS range - Ref.: IOMXXXOPXX00-EN 00
8.3 UPS confi guration table, starting from 0x0001
NOTE!
Fields or bit fields not described must be considered as reserved/unused.
Address Acronym Description Value Default values
0x0001 T000
UPS installation code
and Device type
MSB = UPS
installation
Code (1 byte)
lsb = Device type (1 byte)
(0x01(0x01) unit
(0x06)(0x01) parallel
0x0002 T001
Number of devices in
level -1
1 to 8 (only for parallel system) 1 unit
0x0003 T002
Position of devices
present
each unit present is set by a bit.
If unit 1 present b00 = 1
1 first position by
default
0x0004 T003 Device number 1 to 8 1 o 8
0x0005 T004 Nominal kVA *10 if 0x000E = 1
depends on the
number of units
0x0006 T005 Nominal kW *10 if 0x000E = 1
depends on the
number of units
0x0007 T006 Phase number
MSB = Input
phases 1 – 3
LSB = Output phases 1 - 3 (0x03)(0x03)
0x0008 T007 Function
b00 eco mode enabled
b01 energy saver enabled
b02
b03 genset present
b04
b05
b06
b07
b08
0x0009 T008 Environment
b00
b01
b02
b03
b04
b05
b06 Without bypass
0x000A T009 DC storage
b00 battery present
b01
0x000B T010 Power share
0x000D T012 free free
0x000E T013 measurements factor 0 = no factor / 1 = factor * 10 set to 1
0x000F T014
Device reference
code
0x8200 = BC+
0x8300 = GP4
