8.8 UPS alarms table, starting from 0x0038 or 0x(u)038
MASTERYS BC+ & GP4 ALARMS
Generic ad-
dress
Bits Acronym Description
0x0038
b00 A000 Imminent Stop
LOAD
b01 A001 Overload
b02 A002 Ambient Temperature Alarm
b03 A003 Transfer locked
b04 A004 Transfer impossible
b05 A005 Insufficient Resources
b06 A006 Redundancy lost
b07 A007
b08 A008 Eco mode disabled by UPS
MODE
b09 A009
b10 A010 On Bypass for 1 hour
b11 A011
b12 A012 Maintenance Alarm
SERVICE
b13 A013 Remote Service Alarm
b14 A014 Remote Service Preventive Alarm
b15 A015 General Alarm
0x0039
b00 A016 Battery disconnected
BATTERY
b01 A017 Battery discharged
b02 A018
b03 A019 Operating on Battery
b04 A020 Battery Temperature Alarm
b05 A021
b06 A022 Battery Test failed
b07 A023
b08 A024
b09 A025
b10 A026 Insulation Failure
b11 A027 Battery Alarm
b12 A028
b13 A029
DC STORAGEb14 A030
b15 A031
0x003A
b00 A032 Rectifier Critical Alarm
RECTIFIER
b01 A033 Rectifier Preventive Alarm
b02 A034
b03 A035 Rectifier Input Supply not OK
b04 A036 Gen Set Alarm
b05 A037 Charger Critical Alarm
b06 A038 Charger Preventive Alarm
b07 A039
b08 A040 Inverter Critical Alarm
INVERTER
b09 A041 Inverter Preventive Alarm
b10 A042
b11 A043 Imminent redundancy lost
b12 A044 Consumable alarm
b13 A045
b14 A046 Parallel board Critical alarm
b15 A047 Parallel board Preventive alarm
