6.13 Commands table, starting from 0x00C9
To send a command bit, write to the 0x00C9 or 0x00C8 address using the function code '0x06'. See 'Functions
used' and 'Summary of frame format paragraphs for Modbus frame description.
Each bit defines a command to be executed by the UPS.
It is necessary to change the parameter 'REMOTE CONTROL' to 'enabled' on the mimic-panel to allow the
command to be received; then the related permission P000 switches to 1.
P000 set to 0 means that remote commands are not permitted.
Address
Only for SYSTEM/UPS view
Bit Acronym Description Permission
0x00C9
b00 C000 Reserved
0x00C9
P000
b01 C001 P001
b02 C002 P002
b03 C003 P003
b04 C004 P004
b05 C005 P005
b06 C006 P006
b07 C007 P007
b08 C008 P008
b09 C009 P009
b10 C010 P010
b11 C011 P011
b12 C012 P012
b13 C013 P013
b14 C014 P014
b15 C015 P015
0x00C8
b00 C016 eco mode On
0x00C8
P016
b01 C017 eco mode Off P017
b02 C018 P018
b03 C019 P019
b04 C020 P020
b05 C021 P021
b06 C022 P022
b07 C023 P023
b08 C024 P024
b09 C025 P025
b10 C026 P026
b11 C027 P027
b12 C028 Battery Test P028
b13 C029 P029
b14 C030 P030
b15 C031 Reset Alarm P031
If the bit associated with commands is set to 1, this means the command is enabled by the UPS, and available to
run.
