socomec NETYS PR - 1500-2000 VA and 3000 VA Connection Diagrams

NETYS PR
1000-3000 VA
ENGLISH
IOMNETPRXX00-GB_02 19
8
CONNECTIONS
UPS Battery External battery
IN 230 V~
Use the server’s
supply cord
(IEC 320)
OUT 230 V~
6 x IEC320
1500 VA
2000 VA
3000 VA
OUT 230 V~
8 x IEC320
OUT 230 V~
16 A full load
IN 230 V~Battery connection
for external extension
