3.5 Application modes
3.5.1 Typical energy storage system
A typical energy storage system with PV panels and battery unit(s),
connected to the grid.
3.5.2 System without PV connection
In this configuration, there are no PV panels connected and the
battery is charged through the grid connection.
AMASS-
Storage
Battery
Normal Load
WiFi/GPRS，
RS485,USB,CAN2.0
Grid
Critical Load
Power Generation Date
Monitoring Platform
PV panels
Smart Meter
Hydbrid Inverter
AMASS-
Storage
Battery
Normal Load
WiFi/GPRS，
RS485,USB,CAN2.0
Grid
Critical Load
Power Generation Date
Monitoring Platform
Hydbrid Inverter
Smart
Meter
PV panels
