ELECTRICAL CONNECTIONS
78 HYD 5K...20KTL-3PH
5.11 System monitoring
The HYD 5K ... 20KTL-3PH inverters provide various communication
methods for the system monitoring:
RS485 or WiFi stick (standard), GPRS or Ethernet stick (optional).
5.11.1 RS485
You can connect RS485-linked devices to your PC or a data logger via
an RS485 USB adapter.
• The RS485 line may not be any longer than 1000 m
• Assign each inverter its own modbus address (1 to 31) via
the LCD display
5.11.2 WiFi-, GPRS-, Ethernet stick
When you have installed the stick logger, the inverters can directly
upload your operating, energy and alarm data in the SolarMAN
monitoring portal.
