3.6 Connecting GTX 3000-H batteries
Using SOFARSOLAR's own battery system GTX 3000-H is the easiest
way to build scalable battery systems. A GTX 3000 battery module has
a nominal capacity of 2,5 kWh, allowing multiple configurations for
one tower from 10 kWh (GTX 3000-H4) to 25 kWh (GTX 3000-H10).
Up to four battery towers can be connected in parallel.
Up to four battery towers connected in parallel can be connected to
each of the HYD 5K...20KTL-3PH's battery input, with the same DC
voltage, resulting in a nominal battery capacity of 200 kWh in the
largest configuration.
The HYD 5 ... 8KTL-3PH models have one battery input (max. current
25 A).
The HYD 10 ... 20KTL-3PH models have two battery inputs (max.
current 25 A / 25 A). Battery inputs can be set in parallel mode to
