ELECTRICAL CONNECTIONS
60 HYD 5K...20KTL-3PH
NOTE
• The functions of the communications interface must be
set on the inverter's LCD display. Please observe the
operating steps in chapter 7.
5.9.2 RS485
For the monitoring and control of several inverters, you connect the
RS485 wires in daisy-chain.
At the last inverter, you need to terminate the bus with an 120 Ohm
resistor between Pin 3 and 4.
