INSTALLATION
32 SOFAR 1100...3300TL-G3
4.8 Installation of the inverter
1 Hold the wall bracket in the desired place and mark the three
holes. Put the wall bracket aside and drill the holes.
2 Insert the complete dowel into the hole vertically.
3. Fasten the rear panel to the wall using the three screws.
3 Place the inverter in the wall bracket. Secure the inverter to the
wall bracket using a M5 hexagon screw.
4 You can secure the inverter to the wall bracket using a lock.
