ELECTRICAL CONNECTIONS
SOFAR 1100...3300TL-G3 43
1. Disassemble the connector in accordance with the following
illustration: guide the AC output cable through the cable gland;
Type I
Type II
2. Connect the AC output cable in accordance with the following
requirements and tighten the terminal using the Allen key (type 1)
or the Phillips head screwdriver (type II).
Type I
