ELECTRICAL CONNECTIONS
SOFAR 1100...3300TL-G3 45
Type II
4. Connect the AC connector to the AC connection of the inverter by
turning it clockwise until it locks into place.
5. Remove the AC connector by turning it anticlockwise (type I) or
turning the unlocking switch to the “unlock” position (type II).
CAUTION
Electrical voltage
• Ensure that the grid has been switched off before removing
the AC connector.
