SOFAR 60-80KTLX-G3 User manual
Copyright © Shenzhen SOFARSOLAR Co., Ltd.
Figure 2-3 Front, side and back of the machine (80KW)
Figure 2-4 Bottom view of the machine (80KW)
Function description of inverter box bottom
5. USB Port (for WIFI or GPRS communication)
6. COM Port (for RS485 communication)
3. DC positive poles connectors
4. DC negative poles connectors
Figure 2-5 Bottom view of SOFAR 60~80KTLX-G3
