6.
Commissioning of inverter
Outlines this Chapter
Introduce SOFAR 60~80KTLX-G3 on-grid inverter safety inspection and start
processing
6.1. Cable Connection Inspection
For first time operation (commissioning), should have a all-sided
check. Especially, check the AC voltage and DC voltage are
within the acceptable range
Attention
AC grid connection
Use multimeter to confirm whether L1, L2, L3(live wire), N(neutral wire),
PE(ground wire) and AC terminals are properly connected.
DC pv connection.
Use multimeter to confirm that positive pole and negative pole of PV strings, and
the Voc of each string is lower than the inverter max DC input.
6.2. Start Inverter
Step 1: Turn ON the DC switch.
Step 2: Turn ON the AC circuit breaker.
When the DC power generated by the solar array is enough, the SOFAR
60~80KTLX-G3 inverter will start automatically. Screen showing“normal”indicates
correct operation.
NOTE 1: Choose the correct country code. (refer to section 7.3 of this manual)
NOTE 2: Different distribution network operators in different countries have different
requirements regarding grid connections of PV grid connected inverters.
Therefore, it's very important to make sure that you have selected the correct
