5.Electrical Connection
Outlines of this Chapter
This section introduces the electrical connection for the SOFAR 60~80KTLX-G3
on-grid inverter. Please read the information carefully, it may helpful to understand
the grounding wiring, DC input connection, AC output connection and
communication connection.
Caution:
Before performing electrical connections, ensure the DC switch is OFF and AC
circuit breaker is OFF. Waiting 5 minutes for the capacitor to be electrically
discharged.
Installation and maintenance should be done by certified electrical
engineer
Attention
Before the electrical connection, use opaque material to cover the
PV modules or disconnect PV string DC switch. PV arrays will
produce dangerous voltage if it is exposure under sun
Danger
For SOFAR 60~80KTLX-G3 on-grid inverter, the open circuit
voltage of PV strings should not exceed 1100V
Note
The connected panel must meet the standard IEC61730A.
Item
Model
IscPV(Maximum)
Maximum output
current
SOFAR 60KTLX-G3
6*50A
6*32A
SOFAR 80KTLX-G3
6*60A
6*40A
*SOFAR 70KTLX-G3
6*60A
6*40A
