PSX-NL4 Network Module - Operation Manual
2.2.10 Setting up the Parameters for the Email Reports
The PSX-NL4 can send email alerts based on selectable conditions. If enabled, when the selected conditions are met, the PSX-NL4
will send an email with an attached report file (in CSV format). To set up the email alert conditions, click the "Reporting" link in the top
menu.
Select the Email Alert Triggers
The "Alert Enable On" block of the Reporting page contains checkboxes for the various conditions that can cause an email alert to
be sent (See Figure 2.8).
System Fault If checked, a System Fault condition on a connected device will generate an email alert.
AC Fault If checked, an AC fault condition on a connected device will generate an email alert.
Hall Sensor 1 If checked, a current outside the range set for Hall Sensor 1 will generate an email report.
External Temperature If checked, an external temperature outside of the range set on the Configure page will generate an email alert.
Event1 If checked, a valid input on the Event1 Input will generate an email alert.
FAI Active If checked, an active FAI Input on a connected device will cause an email alert.
Hall Sensor 2 If checked, a current outside the range set for Hall Sensor 2 will generate an email report.
Battery End of Life If checked, an email alert will be sent when the Battery Runtime of the connected device reaches the "Rated
Battery Life" setting on the Configure page. When a new battery is installed, the "Reset Timer for New Battery
Installation" box on the Programming page should be set to reset the Battery Runtime counter.
Battery Condition An email alert will be sent when the battery charge is less than 20% (one yellow bar on the "Bat. Condition"
display on the Home page).
ADC1 Reading If checked, a voltage outside the range set for ADC1 will generate an email report.
Service Reminder An email alert will be sent when the "Next Service Due" date and time on the Configure page are reached.
Device Detect An email alert will be sent when a SPI device (PSX) is connected or disconnected from the PSX-NL4 board.
This will notify the email recipient if the PSX-NL4 loses communication with a connected device.
After setting the email alert triggers, click the "Submit" button at the bottom of the "Alert Enable On" section for the settings to take
effect.
Select the Occurrences to Report
The "Select Occurrences to Report" block of the Reporting page allows the setting of the number of history events which will be in-
cluded in the report file attached to the alert email (See Figure 2.8). The PSX-NL4 records a snapshot of device parameters at the time
period selected on the Configure page. Up to 1000 history events can be recorded. The user can enter between 1 (the latest event
only), up to 1000 (for all events). After entering the number of history events to email, click the "Submit" button to save this setting
