LED Control
23
RM LEDs
Table 9 describes the various conditions indicated by the red, green, and
yellow RM reader LEDs.
TABLE 10. RM Reader LED Indications
Red LED Yellow Green Indication
Brief flash Brief flash Brief flash Power up
Off Off Off Online (software flag enabled)
Off On Off Online
On Off Off Offline or reader tamper
Solid for 1 sec. Off Off Access denied
Fast flash for 2 sec. Off Off Access denied (Software Flag
Enabled)
Off Off On Access granted or door unlocked
(Software Flag Enabled)
Off Off Fast flash Access granted
Off Off Slow flash Door unlocked
Off Slow flash Off Enter second card (escorted access
only)
Off Fast flash Off Enter PIN
Off Fast flash Off Enter floor # (systems configured for
elevator control only)
Flash w/ each key
press
Unchanged Flash w/ each key
press
Keypad input
Slow flash Off Off Reader not configured
Fast flash Fast flash Fast flash Alarm: door forced/held open
On On On Error condition: Remove power to
prevent damage to RM
