Installation Requirements
27
INSTALLATION
REQUIREMENTS
The Software House RM-DCM-2 enclosure accommodates an RM-4E
board, as well as three additional Software House boards. The enclosure
door is hinged, for ease of installation, and includes a tamper switch and
key lock.
This section describes the dimensions and installation requirements for
the RM-DCM-2 enclosure and modules.
Installing the Enclosure
Make sure the installation location provides sufficient space for the RM-
DCM-2 enclosure, and the necessary electrical conduit.
Figure 16 gives the dimensions in inches for mounting the RM-DCM-2
enclosure.
FIGURE 16. RM-DCM-2 Enclosure Dimensions (in Inches)
